Materials
Additional materials and material combinations are available. Please contact a sales representative or request technical support for further information.
Description |
ITEQ IT140 140 Tg / ------ |
ITEQ IT158 158 Tg / 345 TdITEQ IT180 170 Tg / 350 TdITEQ IT180A 170 Tg / 350 Td |
ISOLA 370 HR 180 Tg / 340 TdISOLA FR408 180 Tg / 360 TdISOLA FR408HRP 180 Tg / 360 Td
ISOLA I-SPEED 180 TG / 360 td
ISOLA I-Tera MT40 200 TG / 360 TD
Isola Tachyon 100g 185 TG / 380 TD |
NAN YA NP 140 140 Tg / 340 TdNAN YA NP 180 180 Tg / 340 Td |
ROGERS R4003C 280 Tg / 425 TdROGERS R4350B 280 Tg / 390 Td |
TU-768 180 Tg / 350 Td
TU-872 LK 280 Tg / 425 TdVentec VT-47 280 Tg / 345 Td |
ARLON 91ML Thermally Conductivity of 1.0W/m-K (Used with Metal-Clad PCBs)ARLON 92MIL Thermally Conductivity of 2.0W/m-K (Used with Metal-Clad PCBs) Laird (Thermagon) - T-pregHTD03 - PrePreg Laird (Thermagon) - T-lam-SS-1KA - LaminateLaird (Thermagon) - T-lamSSHTD - Laminate Laird (Thermagon) Manufacturing guideline Definitions: SINGLE SIDED - Copper circuits one side with a 5 mil dielectric on an Alum. or Copper base .020 to .125 thick DOUBLE SIDED - Copper circuits two sides, dielectric and plated through holes bonded to an Aluminum or Copper substrate .020 to .125 thick. MULTILAYER - Board with internal core and epoxy insulating the plated holes connecting the 2 circuit sides |
